Double Wire Fence

Product Description

Double wire fence, known as double horizontal wire fence, 2D panel fence, or twin wire fence. Each welded point is welded with one vertical and two horizontal wires; compared with ordinary welded fence panels, double wire fence has higher strength and can withstand larger impacts and high winds.


Double wire fence is made of high quality low carbon steel wire, the surface treatment is hot dip galvanized, powder coating or PVC coating, which can make mesh fencing have a longer service life. The most common styles include 656 double wire fence and 868 double wire fence, 656 twin wire mesh means horizontal direction is two 6mm thick wire, vertical direction is one 5mm wire.


Double wire fence panels are versatile security solutions ideal for critical infrastructures like power plants, airports, and stadiums, as well as commercial spaces and residential areas. With welded mesh construction, twin wire fences offer sturdy perimeter security for diverse environments.

Product Specification

Double wire fence PanelWire ThicknessPanel WidthHeightSurface Coating
Spacing between horizontal wire:
100mm, 150mm, 200mm.
Spacing between vertical wire:
50mm, 55mm.
8mm/6mm/8mm
or
6mm/5mm/6mm
2.0m
or
2.50m
or
3.0m
1030mmHot Dipped Galvanized
(505g/m²)
OR
Electric Galvanized + Polyester
Powder Coated
(All colors in Ral)
1230mm
1430mm
1630mm
1830mm
2030mm
2230mm
2430mm
2530mm



Post TypeSizeThicknessHeight
Square post50x50mm, 60x60mm1.5mm, 2.0mm, 2.5mm, 3.0mm1.4m, 1.6m, 1.8m, 2.0m, 2.5m, 2.8m, 3.0m
Rectangular post40x60mm, 40x80mm1.5mm, 2.0mm, 2.5mm, 3.0mm1.4m, 1.6m, 1.8m, 2.0m, 2.5m, 2.8m, 3.0m

Product Details

Product Type:

Material: Low carbon steel wire

Wire: 6/5/6mm, 8/6/8mm

Mesh: 50*200mm, 50*100mm, etc.

Height: 1.2m-3m

Width: 2-3m

Post: 60*60mm, 80*80mm, 100*100mm, etc.

Accessories: Post caps, clips or flat bar, nuts and bolts

Surface treatment: Hot dipped galvanized, PVC coated, powder coated

Packaging: Metall pallets

Certificates: ISO9001, BV, SGS

Double Wire Fence Features

Double Wire Fence Features

1. Easy Installation

2. Cost effective

3. Solid, Acid-resistant, alkali-resistant, firm welding, strong anti rust and anti corrosion ability, beautiful, and wide usage.

4. Different options on color according to the using environment

5. Different options of install clips such as metal or plastic

6. Mclassic Metal provides free samples and technical guidance.

As a professional double wire fence supplier, Mclassic Metal has full industry chain and strict quality control flow, with superior raw material, highly skilled technicians, advanced equipment, dedicated workmanship, perfect surface treatment, those to ensure state of art double wire fence. We can also customize a suitable set according to the customer's conditions.

Product Packing & Shipping

Product Packing & Shipping

Fence packing

Plastic film at the bottom to avoid the panel be destroyed

4 metal corners to ensure the panel strong and uniform

Wood plate at the top of pallet to keep the under panel

Pallet tube size:40*80mm tubes at the bottom vertical position

Post & Accessories packing

The caps have been installed on the top of post, which reduce your labor cost and installing time

Each post are packed by a long plastic bag avoiding damaged by friction

All posts are packed by metal pallet for loading and unloading

Clips and screws are packed by sets, plastic film + carton box.

FAQ

Q: Are you manufacturer or trader?

A: We are manufacturer,and we are in fence field for more than 20 years.

Q: What's the lead time?

A: Normally our lead time is 15-25 days after we received the down payment. Urgent order can be negotiated.

Q: Can you provide samples?

A: Yes, we can provide samples with free charge, but the express cost need you pay first. When you placed the order, we will deduct the express cost from the contract amount.

Q: How do you control the goods quality?

A: We have the strict Quality Control System. And our quality inspector will record the production process and inspection from beginning to end in the form of photos or videos to you.

Q: Do you have quality guaranteed?

A: Yes, most of our products have a more than 10 years Quality Guarantee.

Q: Could you supply Door-to-Door Delivery?

A: Yes, we are very good at Door to Door Delivery, please inform me your detailed address, then I will quote you the freight cost to your home directly.

Q: How do we go to your factory for visiting?

A: Please inform me your flight time, we will pick you up at our nearby airport, then drive to our factory for visiting.
